In an AC electrical system, voltage is an important factor to consider when designing and implementing electrical equipment. Two commonly used voltage measurements in AC systems are phase voltage and line voltage. Although they may seem similar, there are significant differences between them. Phase voltage refers to the voltage measured across a single phase of an AC system. In a three-phase system, there are three phases, each separated by 120 degrees. The phase voltage is measured between a phase and the neutral wire. It is also known as the phase-to-neutral voltage. The voltage measured for each phase will be the same in a balanced three-phase system.

On the other hand, line voltage refers to the voltage measured between any two phases in a three-phase system. This measurement is also known as the phase-to-phase voltage. In a balanced three-phase system, the line voltage is equal to the square root of 3 times the phase voltage.

The difference between phase voltage and line voltage can have significant implications for electrical equipment. For example, if a motor is designed to run on a particular line voltage, it will not operate correctly if it is connected to a phase voltage of the same value. Similarly, if a transformer is designed to operate on a particular line voltage, it will not be able to handle the same amount of power if it is connected to a phase voltage of the same value.

In summary, phase voltage is the voltage measured across a single phase of an AC system, while line voltage is the voltage measured between any two phases in a three-phase system. Understanding the differences between these two voltage measurements is crucial when designing and implementing electrical equipment.
