What are the Advantages of Using Continuous-type Winding in High-voltage Transformers?

In transformer design, the choice of winding type is of vital importance. For high - voltagewinding, continuous - typewinding have unique advantages, which lead to their wide adoption in numerous applications such as the SG10 product. Below, we will discuss their advantages in detail.

Content

●Good End - support and Stability
When high - voltagewinding adopt the continuous - type, they have a large end - support area. During the operation of the transformer, especially in the case of a short - circuit, the axial force does not change much. This is because the structural characteristics of the continuous - type winding enable it to maintain better stability when withstanding the electromagnetic force generated by the short - circuit current. Compared with other winding types, this stability can effectively prevent the winding from deforming, displacing, and other problems caused by sudden changes in the axial force, ensuring that the transformer can still operate normally under complex working conditions and greatly improving the transformer's ability to handle sudden situations such as short - circuit faults.

●Excellent Heat - dissipation Performance
The continuous - type winding has good heat - dissipation performance. The structure of the continuous - type winding is conducive to heat transfer and dissipation, enabling the winding to maintain a relatively low temperature during the working process, reducing problems such as insulation aging caused by overheating, and also helping to improve the load - carrying capacity of the transformer and ensuring its reliability during high - load operation.

●Good Manufactureability
The continuous - type winding has certain advantages in the manufacturing process. Its winding process is relatively mature, and the production efficiency is relatively high, which can ensure the consistency and quality stability of the winding. For enterprises that produce transformers on a large scale, this can reduce production costs, improve production efficiency, and is more convenient in terms of quality control.

In Summary

In conclusion, due to its advantages in end - support stability, heat - dissipation performance, and manufactureability, the continuous - type winding is very suitable as a form of high - voltage winding. In products such as SG10, the application of this winding type provides a powerful guarantee for the stable and efficient operation of the transformer. Of course, different application scenarios may require comprehensive consideration of various factors, but in most high - voltage environments, the advantages of the continuous - type winding make it a preferred choice.
