What are the rules and requirements for winding high-frequency transformers?

For spaced winding, ensure that the winding is completely uniform and evenly spaced.

For close winding, ensure that the wires are uniformly tight and closely arranged.

Maintain a sufficient safety distance A and B between the edges of the coil and the edges of the winding slot on both sides.

The length of the sleeve must be sufficient, with one end extending into the winding tube within the safety tape and the other end extending beyond the top edge of the bobbin, but not close to the pin.

The outermost tape should be cut at the interface of the core assembly, and the cutting edge must be covered by the core.

Ensure that the edges of the tape are aligned with the winding slot, and that the tape is not skewed, folded, or damaged.

Tape must be applied under the crossover wire to insulate it from the coils underneath.
